[root@vm10-0-0-117 opt]# cat loadgen.yml
variables:
  - name: ip
    type: file
    path: dict/ip.txt
  - name: message
    type: file
    path: nginx.log
  - name: user
    type: file
    path: dict/user.txt
  - name: id
    type: sequence
  - name: uuid
    type: uuid
  - name: now_local
    type: now_local
  - name: now_utc
    type: now_utc
  - name: now_unix
    type: now_unix
  - name: suffix
    type: range
    from: 10
    to: 13
requests:
  - request:
      method: POST
      runtime_variables:
        batch_no: id
      runtime_body_line_variables:
        routing_no: uuid
      basic_auth:
        username: elastic
        password: xxxx
      url: http://10.0.128.58:8000/_bulk
      body_repeat_times: 5000
      body: "{ \"create\" : { \"_index\" : \"test-$[[suffix]]\",\"_type\":\"_doc\", \"_id\" : \"$[[uuid]]\" } }\n{ \"id\" : \"$[[uuid]]\",\"routing_no\" : \"$[[routing_no]]\",\"batch_number\" : \"$[[batch_no]]\", \"message\" : \"$[[message]]\", \"random_no\" : \"$[[suffix]]\",\"ip\" : \"$[[ip]]\",\"now_local\" : \"$[[now_local]]\",\"now_unix\" : \"$[[now_unix]]\" }\n"

allow_multi_instance: true
path.data: data
path.logs: log

entry:
  - name: my_es_entry
    enabled: true
    router: my_router
    max_concurrency: 10000
    network:
      binding: 0.0.0.0:8000
    tls:
      enabled: false

flow:
  - name: set-auth-for-backup-flow
    filter:
      - set_basic_auth:
          username: elastic
          password: xxxx
  - name: primary-read-flow
    filter:
      - if:
          cluster_available: ["primary"]
        then:
          - elasticsearch:
              elasticsearch: "primary"
              refresh:
                enabled: true
                interval: 30s
        else:
          - elasticsearch:
              elasticsearch: "backup"
              refresh:
                enabled: true
                interval: 30s

  - name: primary-write-flow #正常的主写流程
    filter:
      - if:
          and:
            - consumer_has_lag:
                queue: "primary-failure"
                group: primary
                name: primary-failure
            - cluster_available: ["primary"]
        then: #集群可用但是集群有堆积的情况，不处理客户端请求，待服务恢复之后再提供服务
          - set_response:
              status: 503
              content_type: "application/json"
              body: '{"error":true,"message":"503 Service Unavailable"}'
          - drop:
        else: # 集群不可用或者集群可用且没有堆积的情况，都直接转发给集群先处理
          - if: #集群如果已经变成不可用状态，则直接丢弃请求，让客户端选择处理，或者也可落地队列确保不丢数据
              not:
                cluster_available: ["primary"]
            then: #如果集群不可用，则直接拒绝客户端请求
              - set_response:
                  status: 503
                  content_type: "application/json"
                  body: '{"error":true,"message":"503 Service Unavailable"}'
              - elasticsearch_health_check: #由请求触发的限速模式下的主动检查后端监控情况
                  elasticsearch: "primary"
              - drop:
            else:
              #- bulk_request_mutate: #修复自动生成 id 的文档，主动生成 id
              #    fix_null_id: true
              #    fix_null_type: true
              #    default_type: _doc
              #    type_rename:
              #      "*": _doc #统一索引的 Type 类型，适合旧版本多 Type 迁移到新版本集群
              #    remove_pipeline: true
              #    generate_enhanced_id: true
              - elasticsearch: #集群可用，直接处理请求
                  elasticsearch: "primary"
                  max_connection_per_node: 1000
                  max_retry_times: 0
                  refresh:
                    enabled: true
                    interval: 30s
              - bulk_response_process: #bulk 出错不继续执行后续 flow，因为成功、失败、非法的请求都已经入队，可以直接退出
                  success_queue: "backup"
                  failure_queue: "primary-failure" #失败的请求，两边的集群都要做一次，避免脏数据
                  invalid_queue: "primary-invalid"
              - flow: # 非 bulk 请求继续判断
                  flows:
                    - primary-response-check

  - name: primary-response-check
    filter:
      - if: #不合法的请求
          and:
            - not:
                in:
                  _ctx.response.status: [ 429 ] #400_500 之间但不包括 429
            - range:
                _ctx.response.status.gte: 400
                _ctx.response.status.lt: 500
        then:
          - queue:
              queue_name: "primary-invalid"
          - drop:
      - if: #正常的请求, 复制到备份集群
          in:
            _ctx.response.status: [200,201]
        then: #仅正常处理的集群才转发给后端集群
          - flow:
              flows:
                - set-auth-for-backup-flow
          - queue:
              queue_name: "backup"
          - drop:
        else: #集群可用的情况下但是失败了，可能存在脏写，将请求放入写入失败队列，后续可以选择两边集群都重做一次，最终确保一致性，写 translog，后续提供 UI 可以进行三方检查：主、备集群和本地日志
          - queue:
              queue_name: "primary-failure"

  - name: primary-failure-primary-post-processing #主集群的故障处理，重试，处理通过 commit，处理失败重试，非法请求丢弃，失败的请求
    filter:
      - if:
          not:
            cluster_available: ["primary"]
        then:
          - elasticsearch_health_check:
              elasticsearch: "primary"
          - sleep:
              sleep_in_million_seconds: 5000
          - drop:
      #- bulk_request_mutate: #修复自动生成 id 的文档，主动生成 id
      #    fix_null_id: true
      #    fix_null_type: true
      #    default_type: _doc
      #    type_rename:
      #      "*": _doc #统一索引的 Type 类型，适合旧版本多 Type 迁移到新版本集群
      #    remove_pipeline: true
      #    generate_enhanced_id: true
      - elasticsearch:
          elasticsearch: "primary"
          max_connection_per_node: 1000
          max_retry_times: 0
          refresh:
            enabled: true
            interval: 30s
      - if: #请求失败了，继续重试，不用复制给备份集群
          in:
            _ctx.response.status: [ 429,0,500,503 ]
        then:
          - drop:
      - bulk_response_process: #bulk 成功执行了，非法消息都入队，其他消息都不用管，继续重试，只有全部成功或者失败的时候才 commit，请求丢给 backup，否则提前结束
          invalid_queue: "primary-invalid" #保存用来查看消息日志
          tag_on_all_invalid: [ "commit_message_allowed" ] #只有都是非法请求的情况下才 commit
          tag_on_all_success: [ "commit_message_allowed" ] #只有都是成功的情况下才 commit
          continue_on_all_error: true #bulk 请求整体响应不是200，继续交由后面的 filter 进行处理
      - if: #其他的非 bulk 请求处理，先处理不合法的请求，主集群都失败了，副集群就不用考虑了
          and:
            - not:
                in:
                  _ctx.response.status: [ 429 ] #400_500 之间但不包括 429
            - range:
                _ctx.response.status.gte: 400
                _ctx.response.status.lt: 500
        then:
          - tag:
              add: [ "commit_message_allowed" ]
          - queue:
              queue_name: "primary-invalid"
          - drop:
      - if:
          in:
            _ctx.response.status: [ 200,201 ]
        then:
          - tag:
              add: [ "commit_message_allowed" ]


  - name: primary-failure-backup-post-processing #备集群的故障处理，重试，处理通过 commit，处理失败重试，非法请求丢弃
    filter:
      - if:
          not:
            cluster_available: ["backup"]
        then:
          - elasticsearch_health_check:
              elasticsearch: "backup"
          - sleep:
              sleep_in_million_seconds: 5000
          - drop:
      - flow:
          flows:
            - set-auth-for-backup-flow
      #- bulk_request_mutate: #修复自动生成 id 的文档，主动生成 id
      #    fix_null_id: true
      #    fix_null_type: true
      #    default_type: _doc
      #    type_rename:
      #      "*": _doc #统一索引的 Type 类型，适合旧版本多 Type 迁移到新版本集群
      #    remove_pipeline: true
      #    generate_enhanced_id: true
      - elasticsearch:
          elasticsearch: "backup"
          max_connection_per_node: 1000
          max_retry_times: 0
          refresh:
            enabled: true
            interval: 30s
      - if: #请求失败了，继续重试
          in:
            _ctx.response.status: [ 429,0,500,503 ]
        then:
          - drop:
      - bulk_response_process: #bulk 成功执行了，非法消息都入队，其他消息都不用管，继续重试，只有全部成功或者失败的时候才 commit，请求丢给 backup，否则提前结束
          invalid_queue: "backup-invalid" #保存用来查看消息日志
          tag_on_all_invalid: [ "commit_message_allowed" ] #只有都是非法请求的情况下才 commit
          tag_on_all_success: [ "commit_message_allowed" ] #只有都是成功的情况下才 commit
          continue_on_all_error: true #bulk 请求整体响应不是200，继续交由后面的 filter 进行处理
      - if: #其他的非 bulk 请求处理，先处理不合法的请求，主集群都失败了，副集群就不用考虑了
          and:
            - not:
                in:
                  _ctx.response.status: [ 429 ] #400_500 之间但不包括 429
            - range:
                _ctx.response.status.gte: 400
                _ctx.response.status.lt: 500
        then:
          - tag:
              add: [ "commit_message_allowed" ]
          - queue:
              queue_name: "backup-invalid"
          - drop:
      - if:
          in:
            _ctx.response.status: [ 200,201 ]
        then:
          - tag:
              add: [ "commit_message_allowed" ]


  - name: backup-flow-replicate-processing
    filter:
      - if:
          not:
            cluster_available: ["backup"]
        then:
          - elasticsearch_health_check:
              elasticsearch: "backup"
          - sleep:
              sleep_in_million_seconds: 5000
          - drop:
      - retry_limiter:
          queue_name: "backup-deadletter_requests"
          max_retry_times: 60
          tag_on_success: ["commit_message_allowed"]
      - flow:
          flows:
            - set-auth-for-backup-flow
#      - bulk_request_mutate: #修复自动生成 id 的文档，主动生成 id
#          fix_null_id: true
#          fix_null_type: true
#          default_type: _doc
#          type_rename:
#            "*": _doc #统一索引的 Type 类型，适合旧版本多 Type 迁移到新版本集群
#          #              index_rename:
#          #                test: "test-backup"
#          remove_pipeline: true
#          generate_enhanced_id: true
#          when:
#            contains:
#              _ctx.request.path: /_bulk
      - elasticsearch:
          elasticsearch: "backup"
          max_connection_per_node: 1000
          max_retry_times: 0
          refresh:
            enabled: true
            interval: 30s
      - bulk_response_process: # 如果部分请求出错，保存相关的消息到队列后，直接结束，不继续后续流程的处理
          invalid_queue: "backup-invalid"
          failure_queue: "backup-failure"
          tag_on_all_success: ["commit_message_allowed"]
          tag_on_all_invalid: ["commit_message_allowed"]
          tag_on_any_error: ["commit_message_allowed"]
          continue_on_all_error: true #bulk 请求整体响应不是200，继续交由后面的 filter 进行处理
          when:
            contains:
              _ctx.request.path: /_bulk
      - if:
          in:
            _ctx.response.status: [ 200,201,404,400 ]
        then:
          - tag:
              add: ["commit_message_allowed"]

  - name: backup-flow-reshuffle-replicate-processing
    filter:
      - if:
          not:
            cluster_available: ["backup"]
        then:
          - elasticsearch_health_check:
              elasticsearch: "backup"
          - sleep:
              sleep_in_million_seconds: 5000
          - drop:
#      - bulk_request_mutate: #修复自动生成 id 的文档，主动生成 id
#          fix_null_id: true
#          fix_null_type: true
#          default_type: _doc
#          type_rename:
#          "*": "_doc" #统一索引的 Type 类型，适合旧版本多 Type 迁移到新版本集群
#          #              index_rename:
#          #                test: "test-backup"
#          remove_pipeline: true # pipeline should be enabled manually, please ensure each cluster has the same setup
#          generate_enhanced_id: true
#          when:
#            contains:
#              _ctx.request.path: /_bulk
#      - record:
#          stdout: true
      - flow:
          flows:
            - set-auth-for-backup-flow
      - bulk_reshuffle:
          when:
            contains:
              _ctx.request.path: /_bulk
          elasticsearch: "backup"
          queue_name_prefix: "async_bulk"
          skip_info_missing: true
          level: node #cluster,node,index,shard
          #partition_size: 3
          fix_null_id: true
          tag_on_success: ["commit_message_allowed"]
      - elasticsearch:
          elasticsearch: "backup"
          max_retry_times: 0
          max_connection_per_node: 1000
          refresh:
            enabled: true
            interval: 30s
      - bulk_response_process: # 如果部分请求出错，保存相关的消息到队列后，直接结束，不继续后续流程的处理
          invalid_queue: "backup-invalid"
          tag_on_all_invalid: ["commit_message_allowed"]
          tag_on_all_success: ["commit_message_allowed"]
          continue_on_all_error: true #bulk 请求整体响应不是200，继续交由后面的 filter 进行处理
          when:
            contains:
              _ctx.request.path: /_bulk
      - if: #不合法的请求
          and:
          - not:
              in:
                _ctx.response.status: [ 429 ] #400_500 之间但不包括 429
          - range:
              _ctx.response.status.gte: 400
              _ctx.response.status.lt: 500
        then:
          - queue:
              queue_name: "backup-invalid"
          - tag:
              add: [ "commit_message_allowed" ] # 非法请求不处理了，commit 继续往后处理
          - drop:
      - if:
          in:
            _ctx.response.status: [ 200,201 ]
        then:
          - tag:
              add: ["commit_message_allowed"]

  - name: request_logging # this flow is used for request logging, refer to `router`'s `tracing_flow`
    filter:
      - context_filter:
          context: _ctx.request.path
          exclude:
            - /favicon.ico
      - logging:
          queue_name: request_logging
          max_request_body_size: 102400
          max_response_body_size: 102400
          when:
            or:
              - equals:
                  _ctx.response.header.X-BulkRequest-Failed: "true"
              - not:
                  in:
                    _ctx.response.status: [ 200,201,404 ]
  - name: deny_flow # this flow is used for request logging, refer to `router`'s `tracing_flow`
    filter:
      - set_response:
          body: "request not allowed"
          status: 500
#_delete_by_query not supported
router:
  - name: my_router
    default_flow: primary-write-flow
   # tracing_flow: request_logging
    rules:
      - method:
          - "GET"
          - "HEAD"
        pattern:
          - "/{any:*}"
        flow:
          - primary-read-flow
      - method:
          - "*"
        pattern:
          - "/_cat"
          - "/_sql"
          - "/_cluster"
          - "/_refresh"
          - "/_count"
          - "/_search"
          - "/_msearch"
          - "/_mget"
          - "/{any_index}/_eql/search"
          - "/{any_index}/_count"
          - "/{any_index}/_search"
          - "/{any_index}/_msearch"
          - "/{any_index}/_mget"
        flow:
          - primary-read-flow
      - method:
          - "*"
        pattern:
          - "/_reindex"
          - "/_delete_by_query"
          - "/_update_by_query"
          - "/{any_index}/_reindex"
          - "/{any_index}/_delete_by_query"
          - "/{any_index}/_update_by_query"
        flow:
          - deny_flow
      - method:
          - "DELETE"
        pattern:
          - "/{any_index}"
          - "/{any_index}/{any_type}"
        flow:
          - deny_flow

elasticsearch:
  - name: backup
    enabled: true
    endpoints:
      - http://10.0.1.15:9200
    basic_auth:
      username: elastic
      password: xxx
    discovery:
      enabled: true
      refresh:
        enabled: true
        interval: 60s
  - name: primary
    enabled: true
    endpoints:
      - http://10.0.1.2:9200
    basic_auth:
      username: elastic
      password: xxx
    discovery:
      enabled: true
      refresh:
        enabled: true
        interval: 60s


pipeline:
  # pipelines for logging
  - name: consume-request_logging_index-to-backup
    auto_start: true
    keep_running: true
    processor:
      - json_indexing:
          index_name: "gateway_requests"
          elasticsearch: "backup"
          input_queue: "request_logging"
          when:
            cluster_available: [ "backup" ]

  # pipelines for primary cluster
  - name: consume-queue_primary-dead_retry-to-primary
    auto_start: false
    keep_running: false
    processor:
      - flow_runner:
          input_queue: "primary-deadletter_requests"
          flow: primary-failure-primary-post-processing
          commit_on_tag: "commit_message_allowed"
          when:
            cluster_available: [ "primary" ]
  - name: consume-queue_primary-failure-to-primary
    auto_start: true
    keep_running: true
    processor:
      - flow_runner:
          input_queue: "primary-failure"
          flow: primary-failure-primary-post-processing
          commit_on_tag: "commit_message_allowed"
          consumer:
            group: primary
            name: primary-failure
          when:
            cluster_available: [ "primary" ]

  - name: consume-queue_primary-failure-to-backup
    auto_start: true
    keep_running: true
    processor:
      - flow_runner:
          input_queue: "primary-failure"
          flow: primary-failure-backup-post-processing
          commit_on_tag: "commit_message_allowed"
          consumer:
            group: backup
            name: primary-failure
          when:
            cluster_available: [ "backup" ]

# option B - pipelines for backup cluster, reshuffle bulk requests
  - name: consume-queue_backup-to-backup
    auto_start: true
    keep_running: true
    processor:
      - disorder_flow_runner:
          input_queue: "backup"
          worker_size: 12
          flow: backup-flow-reshuffle-replicate-processing

  - name: consume-queue_backup-bulk_request_ingestion-to-backup
    auto_start: true
    keep_running: true
    processor:
      #- bulk_indexing:
      - disorder_bulk_indexing:
          worker_size: 6
          max_worker_size: 1000
          bulk:
            compress: true
            batch_size_in_mb: 20
            batch_size_in_docs: 10000
          consumer:
            fetch_max_messages: 1000
          waiting_after:
            - "backup-failure"
          queues:
            type: bulk_reshuffle
          when:
             cluster_available: [ "backup" ]

  - name: consume-queue_backup-failure-to-backup
    auto_start: true
    keep_running: true
    processor:
      - flow_runner:
          input_queue: "backup-failure"
          flow: backup-flow-replicate-processing
          commit_on_tag: "commit_message_allowed"
          when:
            cluster_available: [ "backup" ]

disk_queue:
  sync_every_records: 10000
  sync_timeout_in_ms: 10000
  retention:
    max_num_of_local_files: 3
  compress_on_message_payload:
    enabled: true
